¡¡JIANGYANG-CUMMINS SERIES DIESEL GENERATING SET
¡¡MAIN SPECIFICATION
| Model | GF-20 |
GF-30 |
GF-46 |
GF-75 |
GF-80 |
GF-100 |
GF-150 |
|
| Rated Power (kw) | 20 |
30 |
46 |
75 |
80 |
100 |
150 |
|
| E N G I N E |
Model | 4B3.9-G |
4BT3.9-G |
4BTA3.9G |
6BT5.9G1 |
6BT5.9G2 |
6BTA5.9G2 |
6CTA8.3G2 |
| Rated output(kw) | 24 |
36 |
50 |
86 |
92 |
110 |
163 |
|
| Fuel Consumption (g/kw.h) |
¡Ü225 |
¡Ü210 |
||||||
| Cooling starting method |
Closed water cooled / electric starting |
|||||||
| G E N E R A T O R |
Model | BCI184F |
BCI184H |
UC224E |
UC274C |
UC274C |
UC274D |
UC274H |
| Rated output(kw) | 22 |
30 |
48 |
80 |
80 |
96 |
160 |
|
| Rated Voltage(V) | 400,415,440/200,208,220V or 416,440,480/208,220,240 |
|||||||
| Frequency(Hz) | 50/60 |
|||||||
| Power factor (COS¡é) |
0.8lagging |
|||||||
| Phase Connection |
3-phase 4-wire Y type connection |
|||||||
| Excitation | Brushless |
|||||||
| Voltage Regulation |
A.V.R. |
|||||||
| Net Weight(kg) | 650 |
700 |
830 |
1390 |
1460 |
1530 |
1970 |
|
| Packing size LWH(cm) | 1800x 900x1250 |
1900x 900x1330 |
2350x 920x130 |
2390x 920x1350 |
2450x 980x1500 |
|||
| Model | GF-180 |
GF-200 |
GF-250 |
GF-300 |
GF-400 |
GF-500 |
GF-600 |
GF-800 |
GF-1000 |
|
| Rated Power (kw) | 180 |
200 |
250 |
300 |
400 |
500 |
600 |
800 |
1000 |
|
| E N G I N E |
Model | NT 855-G |
NT 855-GA |
NTA 855-G2 |
NTAA 855-G7 |
KTAA 19-G4 |
KTAA 19-G7 |
KTA 38-G2 |
KTA 38-G5 |
KTAA 38-G7 |
| Rated output(kw) | 205 |
231 |
283 |
343 |
448 |
570 |
664 |
880 |
1100 |
|
| Fuel Consumption (g/kw.h) |
¡Ü210 |
¡Ü206 |
¡Ü200 |
|||||||
| Cooling starting method | Closed water cooled / electric starting |
|||||||||
| G E N E R A T O R |
Model | UCD274J |
UCD274K |
HCI444ES |
HCI444FS |
HCI544D |
HCI544FS |
LVI634E |
LVI634E |
LVI634G |
| Rated output(kw) | 180 |
200 |
260 |
304 |
400 |
500 |
600 |
800 |
1000 |
|
| Rated Voltage(V) | 400,415,440/200,208,220V»ò416,440,480/208,220,240 |
|||||||||
| Frequency(Hz) | 50/60 |
|||||||||
| Power factor (COS¡é) |
0.8lagging |
|||||||||
| Phase Connection |
3-phase 4-wire Y type connection |
|||||||||
| Excitation | Brushless |
|||||||||
| Voltage Regulation |
A.V.R. |
|||||||||
| Net Weight(kg) | 3700 |
3800 |
4300 |
4400 |
4800 |
5700 |
7900 |
8500 |
10200 |
|
| Packing size LWH(cm) | 3100x 1200x1750 |
3250x 1200x1800 |
3300x 1200x1900 |
4160x 1350x2050 |
5000x 1900x2640 |
5500x 1900x2680 |
||||
